Mold Clamp Assembly

DGMF Mold Clamps Co., Ltd - mold clamp assembly

Injection Mold Clamp Assembly

The Injection Mold Clamp Assembly Are Available At DGMF Mold Clamps Co., Ltd. We Offer Inventory, Pricing, Datasheets For Injection Mold Clamp Assemblies. The Quick-change Mold Clamp Assemblies Sets Are READY To Ship.

Ask For A Quote

Click Here
SKU DGMF-MOLD-CLAMP-ASSEMBLY-063-2 Categories ,

Description

What is the mold clamp assembly?

The Mold Clamp Assembly is the mold clamp with the bolt and nut assembly together. It can do the mold clamp assembly with the mold clamping bolts, mold clamping nut, and mold clamp washer, or other mold clamp components specific.

Mold Clamp Assembly is supplied by DGMF Mold Clamps Co., Ltd, the mould clamps manufacturer & mold clamps supplier in China.

We provide the mold clamp assembly with many mold clamp types and bolts and nuts, such as open-toe mold clamps, closed-toe mold clamps, forged mold clamps, die clamps, stamping die press clamps, etc. contact us for more details.

Mold Clamp Assembly Specifications

Mold Clamp Assembly
Specifications L D H D1 H1 Usage Range Mold Plate Hole Spacing
M12 110 63 80 12.8 45 10-35 30   35
M16 110 63 80 16.8 45 15-40 30
130 65 86 16.8 60 15-45 40   50
150 75 100 16.8 65 15-45 35
M20 180 77 105 21 70 20-50 50
200 87 110 21 75 20-50 90   65
M24 220 92 100 25 80 20-65 70   75
250 97 130 25 100 20-65 70   80
M30 250 97 130 30.8 100 20-80 150
270 97 130 30.8 100 20-80



Injection Mold Clamp Assemblies can be used with the below mold clamp components.

mold clamp bolts and mold clamp nuts clamping elements

mold clamp bolts and mold clamp nuts clamping elements



DGMF Mold Clamps Co., Ltd - Forged T slot clamps
DGMF Mold Clamps Co., Ltd – Forged T slot clamps assembly



Mould Clamp sets Mold clamp assembly
Mould Clamp sets Mold clamp assembly



step blocks and strap clamps for CNC machining CNC milling
step blocks and strap clamps for CNC machining CNC milling



Adjustable Clamps universal mold clamps
Adjustable Clamps universal mold clamps



easy mold clamps
easy mold clamps



For more mold clamp styles, such as quick-change mold clamp, Adjustable Clamp Universal Mold Clamp, Closed-end Mold Clamp, Open-end Mold Clamp,  universal mold clamp, easy clamp, step block mold clamp, stepped strap clamp, stamping die clamp, hold down clamp, mold clamp bolts, Forged U Clamps, injection mold clamps, injection mold toe clamps, forged gooseneck clamp, forged T slot clamp, mold clamp specifications, and mold clamp prices, etc.

Please do not hesitate to contact us, thank you.

DGMF Mold Clamps Co., Ltd is the mold clamps Manufacturer in China, also provide injection mold components, die press components, machine tools, fasteners for your best choice.
